238264AAA SJ45 AJ+, SJ60 AJ+
92
Section 7 – Technical Diagrams and Specifications Specifications - Dimensional Data
7.4 Specifications - Dimensional Data
SJ45 AJ+ SJ60 AJ+
Height &
Reach
Working Height - maximum 15.54 m 51 ft 0 in 20.11 m 66 ft 0 in
Platform Height - maximum 13.72 m 45 ft 0 in 18.29 m 60 ft 0 in
Horizontal Reach - maximum 6.93 m 22 ft 9 in 11.56 m 37 ft 11 in
Horizontal Reach - at maximum height 2.98 m 9 ft 10 in 6.2 m 20 ft 4 in
Horizontal Reach - y boom retracted 5.23 m 17 ft 2 in 7.7 m 25 ft 3 in
Tailswing 0.61 m 2 ft 0 in 0.61 m 2 ft 0 in
Up and Over Clearance - at platform 7.53 m 24 ft 8.75 in 8.38 m 27 ft 6 in
Up and Over Clearance - at main boom 7.45 m 24 ft 5.25 in 8.31 m 27 ft 2 in
Platform
Platform Size
0.76 x 1.52 m 30 x 60 in 0.91 m x 2.44 m 36 in x 96 in
0.76 x 1.83 m 30 x 72 in 0.91 m x 1.83 m 36 in x 72 in
Platform Rotation 175° 175° 175° 175°
Platform rotation radius 1.14 m 45 in 1.14 m 45 in
Platform height - stowed 0.28 m 11 in 0.28 m 11 in
Overall railing height 1.35 m 53 in 1.35 m 53 in
Platform railing height 1.11 m 44 in 1.12 m 44 in
Jib
Jib Length 1.42 m 55.75 in 1.60 m 63 in
Jib vertical Range of Motion 2.7 m 106.5 in 2.81 m 9 ft 2.5 in
Jib Range of Motion - down 70° 70° 60° 60°
Jib Range of Motion - up 75° 75° 65° 65°
Dimensional
Data
Height - stowed min. 2.06 m 6 ft 9 in 2.54 m 8 ft 4 in
Stowed length @ min. height 6 m 19 ft 8 in 8.6 m 28 ft 2 in
Stowed length - min. 4.75 m 15 ft 7 in 6.6 m 21 ft 8 in
Width 2.29 m 7 ft 6 in 2.44 m 8 ft
Wheelbase 2.03 m 6 ft 8 in 2.44 m 8 ft
Ground Clearance - chassis 0.39 m 15.25 in 0.37 m 14.5 in
Ground Clearance - front axle 0.33 m 13 in 0.33 m 13 in
Axle Oscillation 0.09 m 3.7 in 0.06 m 2.5 in
Turning Radius - inside 1.5 m 4 ft 11.25 in 2.21 m 7 ft 3 in
Turning Radius - outside 4.34 m 14 ft 3 in 5.31 m 17 ft 5 in
Turret Rotation 360° 360° 360° 360°
