SJ45 AJ+, SJ60 AJ+ 238264AAA
95
Maximum platform capacities (evenly distributed) Section 7 – Technical Diagrams and Specifications
7.9 Floor loading pressure
Model
Weights Pressures
Gross MEWP Weight Weight per Wheel** LCP*** OFL***
kg lb kg lb kPa psi kPa psf
SJ45 AJ+
min* 5075 11 190 1450 3200 766 111 7.6 160
max* 5375 11 850 2725 6000 1026 149 8 168
SJ60 AJ+
min* 8530 18 800 2177 4800 788 114 11.2 233
max* 8980 19 800 4082 9000 1087 158 11.8 245
2122AA
*
Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max:
Maximum MEWP weight (Platform loaded to capacity with options/attachments)
**
Wheel Load is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
***
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the  oor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath
the chassis. This has been calculated by dividing the MEWP weight by the overall  oor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must be able to withstand
more than the values indicated above.
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is generally determined by the
engineer or architect for that particular structure.
7.8 Maximum platform capacities (evenly distributed)
2121AA
SJ45 AJ+
Regular Platform Capacity Derated Platform Capacity*
Capacity
300 kg 660 lb 272 kg 600 lb
Maximum number of people 3 3 1 1
Manual side force 400 N 90 lbf 200 N 45 lbf
Wind rating - 12.5 m/s (28 mph) 12.5 m/s (28 mph)
Tilt cutout setting side-to-side x front-to-back 5 degrees x 5 degrees 5 degrees x 5 degrees
SJ60 AJ+
Regular Platform Capacity Derated Platform Capacity*
High-capacity zone
Capacity
454 kg 1000 lb 454 kg 1000 lb
Maximum number of people 3 3 1 1
Manual side force 400 N 90 lbf 200 N 45 lbf
Low-capacity zone
Capacity 300 kg 660 lb 272 kg 600 lb
Maximum number of people 2 2 1 1
Manual side force 400 N 90 lbf 200 N 45 lbf
Wind rating - 12.5 m/s (28 mph) 12.5 m/s (28 mph)
Tilt cutout setting side-to-side x front-to-back 5 degrees x 5 degrees 5 degrees x 5 degrees
*Refer to Section 3 for the capacity derate switch operation.
