Rough Terrain Scissors
No. Label Pictorial Description
6
Off/Lift/Drive
Select “ ” off, “ ” lift or “ ” drive mode.
7
Emergency Stop
Push to disable controls
8
Lift Enable
Select to enable lift mode.
9
Start Engine
Select to start engine.
10
Glow Plug
Select to activate glow plugs.
11
Choke
Select to operate choke.
12
Horn
Select to sound horn.
13
Low/High Torque
Select “ ” low speed (high torque) or “ ” high speed (low
torque).
14
Controller Connector Pinout
Controller connector pinout
