SKYJACK, Page 40 SJIII Compacts & Conventionals
February 2008
Section 2 - Operation Start Operation
2.10-5 To Drive Forward or Backward
Be aware of blind spots when operating
the aerial platform.
Ensure that there are no personnel
or obstructions in the path of travel,
including blind spots.
1. Activate platform control console (refer to
Section 2.10-3).
2. On platform control console, select lift/off/drive
switch to “
” drive position.
3. Activate and hold “
” enable trigger switch.
4. Move controller handle “
” forward or
“
” backward to desired speed and direction of
aerial platform travel.
5. Return controller to neutral center position to stop.
Release “
” enable trigger switch.
To protect against unintended movement of
the aerial platform, push in the emergency
stop button after you have arrived at your
desired location or elevation.
2.10-6 To Steer
1. Activate platform control console (refer to
Section 2.10-3).
2. On platform control console, select lift/off/drive
switch to “
” drive position.
3. Activate and hold “
” enable trigger switch.
4. Press “
” rocker switch on top of controller
handle in either direction to steer.
Steering is not proportional. Driving and
steering may be active at the same time.
