BEFORE YOU FLY
P-26
Assembly & Operation Manual
It is assumed that the builder of this kit has acquired the basic skills and knowledge
necessary to make a safe and functional radio control installation into a model.
Therefore, these notes are intended only to assist that experience.
Travel adjust measured at root.
1. Elevator 20mm
2. Rudder 25mm
3. Aileron 15mm
4. Flaps take off 15 degrees
5. Flaps landing 45 degrees
NOTE : Make sure flaps travel same. Use Powerbox or Matchbox to match travel.
Flaps should be deployed in landing circuit only below 90mph
CG 220mm—250mm from leading edge at root. Empty tanks, UAT full
and wheels down.
Weight Dry weight will be between 28 and 35 lbs depending equipment.
PSI 80—100 psi for pneumatic system
Power JR equipment operates on 4.8V. If you use 5 cell packs please
use a voltage regulator. I prefer 4 cell 2400mA RX packs.
Lipo packs are standard with Powerbox installations
TX RX Do a complete range check before flight. Do this with turbine
running. Follow manufacturers instructions.
Speed Set the maximum speed to 180mph! The prototype were tested
with Jetcat P-120 and P-160 turbines. More powerful turbines
require extra care and extra reinforcing.
Timer A timer can safe your model. Get into the habit of programming
the timer.
