Assembly & Operation Manual
Trim nose door to fit.
Turn fuselage right side up and glue 3 x door
hinges to fuselage.
Glue door cylinder mount to fuselage and secure
door cylinder. Note color code of air tubing.
Mask door in close position and glue other side of
Door hinges to door. Cut front hinge to clear nose
retract unit.
Once glue has set, check operation of door. Trim door if needed.
TAIL PIPE
Dril holes in mounting lugs of tail pipe.
Make 90 degree bend in each mounting lug.
Slide tail pipe in position. Note: The rear of pipe
must just exit the rear former by 10mm.
Mark location of screws on turbine rail.
Dril pilot holes for self tap screws.
Secure pipe in position and glue end of pipe with silicon glue to former.
Glue bellmouth with silicon glue.
P-18
Photo 42
Photo 43
Photo 44
