General Information and Specifications
2-74
31211015 6036, 6042, 8042, 10042, 10054
2.9.13 Assembly Instructions for Flange
Connections (FL61 and FL62)
1. Ensure sealing surfaces are free of rust, splits, scratches,
dirt, foreign matter, or burrs.
2. Pre-lubricate the O-ring with hydraulic oil.
3. Position flange and clamp halves.
4. Place lock washers on bolt and bolt through clamp
halves.
5. Tighten all bolts by hand.
6. Torque bolts in diagonal sequence in two or more
increments to the torque listed.
