Skyworth 42E68 - Functional Block Diagram

A1 SEMI ELECTRONICS LTD. 3
Functional Block Diagram
GND (Fixed Output)
ADJ (Adjustable Output)
Thermal
Shutdown
Out
+
-
INPUT
OUTPUT
Figure 3. Functional Block Diagram of AS1117
http://www.a1semi.com
AS1117
A1semi 1A Fixed and Adjustable Low
Electronics Ltd Dropout Linear Regulator(LDO)
A1
A1
A1
