IMPORTANT
As in many studios, your computer may be located in a room far away from
your console. For DVI cable lengths over 15ft, a DVI signal booster is required.
This will ensure the video signal reaches the display with no signal degradation.
You will now need to install touch drivers in order to get touch response from
RAVEN MTi.
Software Installation and Touch Calibration
Installing the RAVEN MTi software and calibrating the touchscreen is a quick
process.
IMPORTANT
Calibration is the most important process for accurate use of the screen. Failure
to calibrate properly will result in poor touch performance.
DO NOT RUN ANY APPLICATIONS UNTIL CALIBRATION IS COMPLETED
1. Run the RAVEN MTi installer and download the drivers onto your hard
drive.
2. Restart your computer for changes to take effect.
To calibrate RAVEN MTi use the following procedure:
1 Launch MultiTouchPlatform. This can be found in your application folder.
2 Press calibration button on the home screen.
3 Follow the prompts on the screen and touch the center of each “+” as it
appears.
4 Repeat steps 2-3 until an accurate calibration is achieved.
Important notes about screen calibration.
● Calibration should be done sitting in the center position of the console.
Failure to do so will result in an inaccurate calibration point.
● Calibration must be done using a direct and natural touch angle. Do not
calibrate with a bend in your wrist or from an extreme angle. Failure to
do so will result in an inaccurate calibration.
Correct Touch Angle Incorrect Touch Angle
