BFY – MOUNTING BRACKET FOR POSITIONER FY 5
13 – Put the pressure equivalent to the half
of the stem travel and adjust the height of
the bracket assembly to have the arrows
matching.
14 - Tighten the bolts to fasten the clamps
to the yoke.
If the actuator is pillar type, fasten the U-
clamp nuts.
