10
Preparations – Measuring, cont’d
3.2.1 Settings.
Settings comprises 4 sub-menus (tabs).
Appearance, Browser, Valve Data and
License. Normally it is only Appearance and
Valve Data that is to be set.
3.2.1.1 Appearance.
Tap Appearance.
Five settings are to be done. Language, and
unit choices for DiffPressure, Flow, Static
Pressure and Temperature. Each setting is
represented by a scroll down box. Tap the
arrow and the available choices are
displayed. Tap your choice and the scroll
down box will close and display your unit
choice. Any unit could also be changed
during measuring. By using the icons at the
bottom of the window.
3.2.1.2 Browser
This tab is only used when utilizing the
advantage of communication with alternative
Measuring Sensors.
See ”6. Using several Measuring Sensors”.
