Important Safety Warnings
The Smart Lifter ECO garage door opener described in
this manual is designed for the automation of residential
sectional overhead and tilt doors to a maximum size of
18m
2
that are properly balanced and operating smoothly.
Any other use is considered improper and will void the
warranty.
WARNING:
You are carrying out operations on machine systems
classied in the automatic gates and doors category and
as such failure to comply with the relevant safety rules
may result in serious personal injury and/or property
damage. Reference to the safety rules can be found on
pages 2-4 of the owners manual and should be read and
understood prior to installation.
Only qualied personnel should install and service the
equipment. It is the responsibility of the installer to adhere
to all relevant safety standards.
The Smart Lifter ECO garage door opener is designed
and manufactured to meet all current Australian
standards and it is essential that the installer also installs
the equipment in accordance with all local and Australian
regulations.
Unqualied personnel or those who do not know the
occupational health and safety standards applicable
to the automatic gates and doors category must under
no circumstances carry out installations or implement
systems.
Persons who install or service the equipment without
observing all the applicable safety standards will be
held responsible for any damage, injury, cost, expense
or claim whatsoever suffered by any person as a result
whether directly or indirectly from failure to install the
system correctly and in accordance with the relevant
safety standards and installation manual.
For a more detailed list of the Safety Warnings and
Safety Issues associated with the installation and use
of a Smart Lifter ECO garage door opener refer to the
safety warnings in the OWNERS MANUAL.
Contents
The Smart Lifter ECO garage door opener requires a
240VAC 50Hz power input and has a 24V DC motor
and can provide remote control and automatic modes
for operation. When the door is in operation, movement
can be interrupted by activation of the safety inputs:
transmitter, wall button (if tted) and photo beams (if
tted).
Limits set open and close positions and braking during
the end of the travel cycle reducing speed and noise.
A 433.22MHz radio receiver is built into the circuit board
and the rolling code is memorised via the self-learning
technique. As an alternative to the built-in receiver the
opener will accept any of the range of stand alone radio
receivers. The opener has been designed to provide
maximum reliability, safety and exibility of use.
IMPORTANT:
Before commencing installation please read all of the
instructions carefully and make sure you are familiar
with the safety warnings included in this manual and
in the OWNERS MANUAL.
Description
No Package Part
1 Motor No Description Qty Remark
1 Motor 1 Set
2 Transmitter 2 Pcs 4 Button
3 Remote Wall Switch 1 Pc 2 Button
4 Remote Wall Switch Bracket 1 Pc
5 Disengagement Cord 1 Pc
6 Bracket – Wall 1 Pc For Track
7 Bracket – Door 1 Pc For Hockey Stick
8 U-Bracket 2 Pcs For Track/Motor Assy
9 Hockey Stick 2 Pcs
10 Strapping 2 Pcs For Rail
11 Bolts/Nuts 1 Set
12 Installation Manual 1 Pc
13 Owners Manual 1 Pc
14 Quick Start Guide 1 Pc
15 Risk Of Entrapment Label 1 Pc
2 Rail 1 Extrusion With Chain 1 Set
