8 | CHAPTER 2 – INSTALLING AND SECURING YOUR SMART BOARD
INTERACTIVE WHITEBOARD
Installing your SMART Board interactive
whiteboard
Follow the procedure outlined in the installation document included in your interactive
whiteboard’s box to install your interactive whiteboard. If you purchased a floor stand,
wall-mount or an interactive whiteboard system that includes a projector or other
components, refer to the installation documents included with these components.
The optimal mounting height is 77" (196 cm) from the floor to the center of the
installation brackets. However, consider the general height of your user community
when you choose a location for wall-mounting your interactive whiteboard. If you
mount your interactive whiteboard too low, it might force tall people to bend over
uncomfortably. If it’s too high, other people might need to reach up too far. Also
remember to leave enough room on either side so that you can stand beside it.
WARNINGS
• Two people are required to safely mount your interactive whiteboard because
it is too heavy for one person to safely maneuver. When you and your
assistant lift your interactive whiteboard, support its weight at the bottom,
avoiding the corner cameras, and balance the top with your other hands.
• The weight of the interactive whiteboard is approximately 52 lb. (23.7 kg) for
the SBX880 model and 61 lb. (27.5 kg) for the SBX885 model. Check your
local building codes to ensure that your wall can support this weight, and use
appropriate mounting hardware for your wall type.
Dust • Moderate dust. Intended for use in office and classroom
environments. Not for industrial use where heavy dust
and pollutants can cause malfunctions or impaired
operation.
• Designed for pollution degree 1 (P1) as per EN61558-1,
which is defined as “No pollution or only dry
non-conductive pollution.”
Conducted and
radiated emissions
EN55022/CISPR 22, Class A
Environmental
requirement
Parameter
