SMART forfour - Model plate

No. Consumer Current Colour cod-
ing
18 Electrical exterior mirror 5 A Brown
19 Brake lamps 10 A Red
20 Parking aid, headlamp settings, Lane Keeping
Assist
15 A Blue
21 Engine control unit 5 A Brown
22 Rear window wiper 15 A Blue
23 Starter motor 30 A Green
24 Central locking 40 A Orange
25 Front windscreen wipers 30 A Green
26 Radio 20 A Yellow
27 ‑ ‑ ‑
28 12 V socket, cigarette lighter 15 A Blue
29 Power supply control unit 5 A Brown
30 Horn 15 A Blue
31 ‑ ‑ ‑
32 Central locking 15 A Blue
33 Tail lamps, front foglamps, hazard warning
lamp button, locking button, headlamp range
control, power
windows, licence plate lighting,
radio, control unit for air-conditioning sys-
tem, cruise control, limiter, parking aid but-
ton, program selector button, tailgate unlock-
ing, Lane Keeping Assist camera, automatic
start/stop system button
25 A Cyan
34 Headlamps, daytime driving lamps 25 A Cyan
35 Headlamps, daytime driving lamps 25 A Cyan
36 ‑ ‑ ‑
37 ‑ ‑ ‑
38 ‑ ‑ ‑
39 ‑ ‑ ‑
40 ‑ ‑ ‑
244
Electrical fuses
>> Breakdown assistance.
