SmarTap e-Valve - Page 33

31 of 51
Connect the pipes to the e-Valve, according to the figure below.
WARNING
MAKE SURE THAT THE HOT/COLD INLET IS
CONNECTED TO A WATER INLET BY THE TEXT "IN1
(HOT)"/"IN2 (COLD)" ON THE E-VALVE BOX.
