HGM1780 Automatic Genset Controller
HGM1780 Automatic Genset Controller
not be sent (this only concerns
temperature sensor, not high
temperature signal via config. input
port).
When the external pressure sensor
value falls below this threshold, low
oil pressure delay begins.
Detection begins after safely on
delay. If the set value is 0, low oil
pressure signal is not sent (this
only concerns pressure sensor and
does not concern low oil pressure
warning signal via configurable
input port)
When the liquid level of the
external sensor falls below this
value and stays so for 10 seconds,
low liquid level signal is send and
warning without shutdown is
initiated.
Numbers of generator pole,
When battery voltage exceeds this
value and stays so for 20 seconds,
Battery Over Volts signal is send
and warning without shutdown is
initiated.
When battery voltage falls below
this value and stays so for 20
seconds, Battery Under Volts signal
is send and warning without
shutdown is initiated.
The ratio of external CT.
Default value: 500:5.
Generator‟s rated current; used to
estimate load over current.
When load current exceeds full
current value multiple by this value,
over current delay begins.
When load current exceeds this
threshold and stays so for the pre-
set time, the situation is regarded
as over current.
Default: Auxiliary shutdown; if the
set value is 0, fuel level sensor type
can be selected.
Active delay time for digital input
ports
