HGM4020DC GENSET CONTROLLER USER MANUAL
HGM4020DC Genset Controller Version 1.0 2019-04-10 Page 23 of 31
No.
Items
Range
Default
Description
(0-30000)min
30
Time(Minute)
Duration time
Mains Abnormal And Pile Low Volt Start
1
Start Set
(0-1)
1
0: Not Start; 1: Start
2
Stop Condition
(0-3)
0
0: Pile Volt High and Current Low
1: Pile Volt High
2: Current Low
3: Pile Volt High or Current Low
3
Pile Volt Upper Limit
(0-100.0)V
58.0
It is battery voltage when battery is
completely charged.
4
Pile Volt Lower Limit
(0-100.0)V
45.0
It is battery pack under voltage limit. If
voltage of battery falls below the setting
value, genset will be started.
5
Charge Finish Time
(1-6000)min
720
It is the maximum time to charge for once.
6
Under Current
(1-100)%
15
When load current of switch power is lower
than the set value, and battery voltage is
higher than the upper limit value as well,
genset will be allowed to stop.
7
Under Current Delay
(10-3600)s
30
When genset is normal running, if load
current is below pre-set lower limit value,
this delay will be started.
8
Minimum Charge
Time
(0-360)min
30
When battery charging time exceeds the set
value, and if temperature of machine room is
high, air conditioner will be started.
Mains Abnormal And Room Temp. High Start
1
Start Set
(0-1)
1
0: Not Start; 1: Start;
2
Room Temp. Upper
Limit
(15-55)ºC
28
Genset will start up if machine room is
higher than this value.
3
Room Temp. Lower
Limit
(15-55)ºC
22
After genset starts up because of the high
temp. of machine room, if room temp. falls
below the set value, genset will stop.
NOTES:
1) When parameter configuration is operated via PC software, there is no need to input password if default password
(0318) isn’t changed. On the contrary, if default password has been changed or it is the first time to set parameters via
PC, password is needed to input in the password interface.
2) After the correct password is entered, before LCD backlit gets dark, parameter setting interface can be entered directly
by inputting parameter serial at secondary entering the password interface.
7.2 DEFINABLE CONTENT LIST OF PROGRAMMABLE OUTPUT PORTS 1-5
Table 11 – Definable Contents of Programmable Outputs 1~5
No.
Items
Function Description
0
Not Used
Output port don’t output when it is chosen.
1
Common Alarm
Include all shutdown alarms, trip and stop alarms and warning alarms.
When there is warning alarm only, it is not self-locked; when a shutdown
alarm occurs, it is self-locked until the alarm is reset.
2
Common ELE Trip
Output when a common trip shutdown alarm occurs.
3
Common Shutdown
Output when a shutdown alarm occurs.
4
Common Warn Alarm
Output when a common warning alarm occurs.
5
Audible Alarm
When warning, trip shutdown and shutdown alarms appear, audible
alarm output is fixed for 300s, during which if any button on the panel is
pressed, or “alarm mute” input is active, or any keys on the panel is
active, the alarms shall be removed.
6
Energized to Stop
Applicable for genset with stop electromagnet; it shall pull in when stop
idle speed running ends and disconnect when the set ETS delay is over.
7
Idle Control
Applicable for genset with idle speed; it shall pull in when genset starts
and disconnect when warming up is initiated; it shall pull in during stop
idle speed process and disconnect when genset stops completely.
