HGM4020DC Genset Controller Version 1.0 2019-04-10 Page 6 of 31
3 SPECIFICATION OPERATION
Table 2 – Technical Parameters
Items
Contents
Operating Voltage
DC48V continuous; Range (20-65)V;
Power Consumption
<3W (standby ≤2W)
Alternator Volt Input Range
3Phase 4Wire
3Phase 3Wire
Single Phase 2Wire
2Phase 3Wire
15V AC - 360 V AC (ph-N)
30V AC - 620 V AC (ph-ph)
15V AC - 360 V AC (ph-N)
15V AC - 360 V AC (ph-N)
Alternator Frequency
50Hz/60Hz
Speed sensor voltage
1.0V to 24.0V (RMS)
Speed sensor Frequency
10,000 Hz (max.)
Start Relay Output
8 A DC28V DC B+ power supply output
Fuel Relay Output
8 A DC28V DC B+ power supply output
Fan Relay Output
8 A DC28V DC B+ power supply output
Programmable Relay Output 1
8 A DC28V DC B+ power supply output
Programmable Relay Output 2
8 A DC28V DC B+ power supply output
Battery Pack Volt Input
0V DC - 35 V DC
RS485-1 Interface
Communication port with rectifiers
RS485-2 Interface
Baud rate 9600bps; 2 stop bit; no parity check
Communication protocol YD 6313
Case Dimension
135mm x 110mm x 44mm
Panel Cutout
116mm x 90mm
Working Conditions
Temperature: (-25~+70)°C; Relative Humidity: (20~93)%RH
Storage Condition
Temperature: (-30~+80)°C
Protection Level
Front panel: IP65
Insulating Intensity
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal;
The leakage current is not more than 3mA within 1min.
Net Weight
0.32kg
