Page 20 of 52
HGM6510 GENSET PARALLEL UNIT
latching and stop the Generator.
No
Type
Range
Description
1
Emergency
Stop
Always active
When the controller detects an emergency
stop alarm signal, it will initiate a shutdown
alarm and the corresponding alarm
information will be displayed on LCD.
2
High
Temperature
From “Start Idle”
delay to “Stop
Idle” delay
When the controller detects that
water/cylinder temperature has exceeded
the pre-set value, it will initiate a shutdown
alarm and the corresponding alarm
information will be displayed on LCD.
3
Low Oil
Pressure
From “Start Idle”
delay to “Stop
Idle” delay
When the controller detects that the oil
pressure has fallen below the pre-set value,
it will initiate a shutdown alarm and the
corresponding alarm information will be
displayed on LCD.
4
Over Speed
Always active
When the controller detects that the
generator speed has exceeded the pre-set
value, it will initiate a shutdown alarm and
the corresponding alarm information will be
displayed on LCD.
5
Under Speed
From “Waiting for
load” delay to
“Cooling” delay
When the controller detects that the
generator speed has fallen below the pre-set
value, it will initiate a shutdown alarm and
the corresponding alarm information will be
displayed on LCD.
6
Loss of Speed
Signal
From “Crank
Success” to
“Stop Idle” delay
When the controller detects that the genset
speed is 0, it will initiate a shutdown alarm
and the corresponding alarm information will
be displayed on LCD.
7
Gen Over
Frequency
Always active
When the controller detects that the genset
frequency has exceeded the pre-set value, it
will initiate a shutdown alarm and the
corresponding alarm information will be
displayed on LCD.
8
Gen Under
Frequency
From “Waiting for
load” delay to
“Cooling” delay
When the controller detects that the genset
frequency has fallen below the pre-set value,
it will initiate a shutdown alarm and the
corresponding alarm information will be
displayed on LCD.
9
Gen Over
Voltage
Always active
When the controller detects that the genset
voltage has exceeded the pre-set value, it
will initiate a shutdown alarm and the
corresponding alarm information will be
displayed on LCD.
