Smartgen HGM6510 User Manual

HGM6510 GENSET PARALLEL UNIT
HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 27 of 52
7.1.3 GENERATOR DISPLAY
7.1.2 ENGINE DISPLAY
ENGINE 2-1
First Engine Screen
SPEED 0 RPM
BATTERY 0.0 V
CHARGE D+ 0.0 V
Engine Speed
Generator Start Battery Voltage
AC Charger D+ Voltage
ENGINE 2-2
Second Engine Screen
OIL PRESSURE 0 kPa
0.0 Bar
0 Psi
Engine Oil Pressure
ENGINE 2-3
Third Engine Screen
FUEL LEVEL 0 %
TEMPERATURE 0 °C
0 °F
Fuel Level
Engine Temperature
ENGINE 2-4
Fourth Engine Screen
STARTS 00000 times
Total Start Times
HOURS RUN 00000:00:00
Total Run Time: HH: MM: SS
MAINTENANCE 00000h
The display of the remaining maintenance time
GENERATOR 3-1
First Generator Screen
UL-L 0 0 0 V
UL-N 0 0 0 V
F = 0.00Hz 0 RPM
3-phase Phase Voltage L1-N L2-N L3-N
3-phase Line Voltage L1-L2 L2-L3 L3-L1
Generator Frequency, Engine Speed
GENERATOR 3-2
Second Generator Screen
IL 0.0 0.0 0.0 A
PF 0.00 0.00 0.00
APF 0.00L I0 0.0 A
3-phase Current L1 L2 L3
3-phase Power Factor L1 L2 L3
Generator Frequency Power Factor, Generator Zero
Sequence Current
GENERATOR 3-3
Third Generator Screen
kW 0.0 0.0 0.0
TkW 0.0 Ramp 0.0
kW% 0.0 Tgt% 0.0
3-phase Split-phase Active Power L1 L2 L3
Generator Total Active Power, Pre-set Active Power
Percentage
Active Power Output Percentage, Target Active Power
Percentage
GENERATOR 3-4
Fourth Generator Screen
kVar 0.0 0.0 0.0
TkVar 0.0 Ramp 0.0
kVar% 0.0 Tgt% 0.0
3-phase Reactive Power L1 L2 L3
Total Reactive Power, Pre-set Reactive Power
Percentage
Reactive Power Output Percentage, Target Reactive
Power Percentage
