HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 22 of 52
HGM6510 GENSET PARALLEL UNIT
No
Type
Range
Description
19
Gen Fail to
Open
Always active
If the open signal was not be detected within
the generator breaker open timer, it will
initiate a shutdown alarm and the
corresponding alarm information will be
displayed on LCD.
20
Maintenance
Due
Always active
If maintenance is enabled, when
maintenance countdown time is 0 and the
action select “Shutdown”, it will initiate a
shutdown alarm and the corresponding
alarm information will be displayed on LCD.
21
Gen Phase
Sequence
Wrong
When generator
is normal
When the controller detects a phase rotation
error (correct phase is L1, L2, L3), it will
initiate a shutdown alarm and the
corresponding alarm information will be
displayed on LCD.
22
Bus Phase
Sequence
Wrong
When the bus is
live
When the controller detects a bus phase
rotation error (correct phase is L1, L2, L3), it
will initiate a shutdown alarm and the
corresponding alarm information will be
displayed on LCD.
23
Reverse
Power
Always active
If reverse power detection is enabled, when
the controller detects that the reverse power
value (power is negative) has fallen below
the pre-set value, it will initiate a shutdown
alarm and the corresponding alarm
information will be displayed on LCD.
24
Over Power
Always active
If over power detection is enabled, when the
controller detects that the over power value
(power is positive) has exceeded the pre-set
value, it will initiate a shutdown alarm and
the corresponding alarm information will be
displayed on LCD.
25
Loss of
Excitation
Always active
If “Loss of Excitation” detection is enabled,
when the controller detects that the genset
negative reactive power has exceeded the
pre-set value, it will initiate a shutdown alarm
and the corresponding alarm information will
be displayed on LCD.
26
Bus Fault
Before closing
breaker
when the controller detects that the bus
voltage is 0 and other sets are closed
already, it will initiate a shutdown alarm and
the corresponding alarm information will be
displayed on LCD.
