Smartgen HGM6510 User Manual

HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 37 of 52
HGM6510 GENSET PARALLEL UNIT
input is inactive, the gen-set will automatically open
and stop.
17
Remote Start On Load
Demand
In Auto mode, when the input is active, all the parallel
units are started in the order of priority; then according
to the load, the number of units is automatically
increased or decreased.
18
Scheduled Run Inhibit
In Auto mode, when the input is active, schedule start
is inhibited.
19
Simulate Mains
Available
Reserved
20
Simulate AUTO
Button
External pushbuttons (not self-locking switch) can be
connected to simulate panel pushbuttons.
21
Simulate MANUAL
Button
22
Simulate STOP Button
23
Simulate Test Button
24
Simulate START Button
25
Transfer to Bus
26
Transfer to generator
27
MSC Alarm inhibit
When MSC is disconnected or data error occurs, alarm
signal will be prohibited.
28
Duty Select
When the input is active, priority is the highest; used to
select main/standby generator.
29
Reset Maintenance
Alarm
When the input is active, the controller will reset
maintenance time to its pre-set value and clear the
alarm.
30
Remote Start in Island
Mode
Reserved
31
Mains Parallel Mode
When the input is active, the generator power output is
constant (output power value is defined via PC
software) and will not share load with other generators.
32
Speed Raise
Used in mains parallel mode, inching input; when the
input is active, increase generator active power output
by 1%.
33
Speed Lower
Used in mains parallel mode, inching input; when the
input is active, decrease generator active power output
by 1%.
34
Voltage Raise
Used in mains parallel mode, inching input; when the
input is active, increase generator reactive power
output by 1%.
35
Voltage Lower
Used in mains parallel mode, inching input; when the
input is active, decrease generator reactive power
output by 1%.
36
Black Start Input
When the input is active:
a) Generator transfer failure alarms will not be
detected;
b) When start the gen-set, generator closed output is
