HGM6510 GENSET PARALLEL UNIT
HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 41 of 52
No.
Type
Description
066
Preheat (during
pre-heat timer)
Action from preheat delay till the start of cranking.
067
Preheat (until end of
crank)
Action from preheat delay till the end of cranking.
068
Preheat (until end of
warm timer)
Action from preheat delay till the end of warming up.
069
Preheat (until safety
on)
Action from preheat delay till the end of safety on time.
070
Open Output
Control generator or mains to off load.
071
System in Test Mode
Action when the system is in the test mode.
072
System in Auto Mode
Action when the system is in the Auto mode.
073
System in Manual
Mode
Action when the system is in the manual mode.
074
System in Stop Mode
Action when the system is in the stop mode.
075
Under Speed
Pre-alarm
Action when under speed warning.
076
Under Speed
Shutdown
Action when under speed shutdown.
077
Reserved
078
Idle/High-Speed
Control
Action from “Cranking” delay to “Start Idle” delay and from
“Stop Idle” delay to “Fail to Stop” delay.
079
Pre-oil Supply Output
Action from “Cranking” delay to “Safety On” delay.
080
Raise Speed
Energized
Reserved
081
Excite Generator
Action when cranking; During safety on running, output
2s if there is no generator frequency.
082
Drop Speed
Energized
Reserved
083
Preset to Lubricate
Action from “Preheat” delay to “Safety On” delay.
084
Raise Volt. Output
Reserved
085
Drop Volt. Output
Reserved
086
Reverse Power
Output
When the generator reverse power has exceeded the
pre-set value, the output activates.
087
Over Power Output
When the generator over power has exceeded the pre-
set value, the output activates.
088
Low Water
Temperature Warn
Action when low temperature warning.
089
Generator Volt.
Normal
Action when generator voltage is normal.
090
ECU Power
For engines fitted with ECU; Used for control ECU power
supply.
091
ECU Stop
For engines fitted with ECU; Used for control ECU
shutdown.
NOTE: Functions of 1~5 output ports only can be configured via PC software.
