SmartLabs SML-272 SD - Page 21

Options SML-272 SD
SML-282 HD
Base
SML-292 HD
Premium
RF receiver
Frequency : RF433 MHz
IR/RF IR/RF IR/RF
Device dimensions (L*W*H), mm 150*150*55
Package dimensions (L*W*H), mm 290*230*80
Inputs and Outputs
USB 2.0 at the back panel
А type, 5V 500mA
+ + +
USB 2.0 at the side panel
А type, 5V 500mA
Optional Optional +
Ethernet (10BASE-T, 100BASE-
TX)
Slot: RJ45
+ + +
Composite video output
CVBS
Slot:1xRCA
+ + +
Component video output YPbPr/
RGB
Slot: 3xRCA
Optional Optional Optional
Multimedia output HDMI 1.3a with
HDCP
Slot: HDMI
- + +
Stereo audio output
Slot: 2xRCA
+ + +
S/PDIF Optional + +
Microphone inputs, pcs
Slot: mini-jack 3.5 mm
Optional
(Up to 2)
Optional
(Up to 2)
+ (2)
21
