Appendix 4 – Specification Table
SPECIFICATION TABLE
Number of beams
2 - 128
Object detection
14mm, 30mm, 40mm plus perimeter guarding systems
Detection height
158 – 2424 mm
Range
Perimeter guard - 3.0 – 15m
0.5 – 6m
14 mm guard - 0.5 – 4m
30 mm guard - 0.5 – 6m
40 mm guard - 3.0 – 15m
Light type
Infrared 880nm
Response time
20ms
Operating temperature
-30C to +50C
Light curtain enclosure
IP65 (H x W x D) H x 48 x 61
Power supply
requirement
24V DC 2A 10%
Current consumption
1.5A maximum
Light curtain connection
M12 - 8 way pin - IP65
Finish
Aluminium chromate treated, yellow polyester powder coated
Classification
BS EN 61496-1 Type 4
BS IEC 61496-2 Type 4
EN ISO 13849 – 1 PL e
BS EN 62061 SIL 3
Warranty
1 Year
INPUTS
Safety monitoring (EDM)
ON = +24V DC (3mA)
Reset
ON = +24V DC (3mA)
Mode select
Auto restart with EDM, manual (latched) restart, floating
blanking, fixed blanking, mute delay off time, mute
disparity, mute time out, partial / fixed muting, and restart
interlock.
Muting
ON = +24V DC (3mA) Dual Mute Inputs
OUTPUTS
Safety outputs
OSSD1 & OSSD2
Electronic 500mA
Status output
Electronic 500mA
Mute output
Electronic 500mA
Status and mute indication
Status & condition LEDs on the light curtain
