H ARDWARE D ESCRIPTION
3
Hardware Description
The Fast Ethernet PCI is equipped with:
• 1 RJ-45 connector for 10/100 Mbps connections
• 1 3-pin connector for Wake-On-LAN cable
• 1 Socket for optional boot ROM
•1 LED indicator
The components of the Fast Ethernet PCI are shown in the figure below:
Wake-On-LAN Connector
Optional Boot ROM Socket
LED Indicator
RJ-45 Connector
for 10/100 Mbps
