Capture Console Toolbar
Click “Analysis” to open the capture console.
Start Starts the capture function. You must set filters
using the “Set” button before capturing.
Stop Stops the capture function.
Stop & View Stops the capture function and opens the
“Analysis Packet” screen.
View Opens the “Analysis Packet” screen.
Set Opens the “Filter Setting” screens.
View
Set
Stop & View
Stop
Start
