SMC Networks D-MP Series User Manual

-18-
No.D-※S-OMU0002-A
○Service data
The tables below indicates the parameters which can be read or written by simple access parameter (direct
parameters page) and ISDU parameters which are applicable to various parameters and commands.
•Direct operation parameters
Address
Access
Parameter name
Default (decimal number)
Value
0x07
R
Vendor ID
0x0083(131)
SMC Corporation
0x08
0x09
R
Device ID
0x0125(293)
0x0126(294)
0x0127(295)
0x0128(296)
D-MP025
D-MP050
D-MP100
D-MP200
•ISDU parameters
ISDU
Access
1
Parameter name
Data
storage
2
Value
Index
(decimal number)
Subindex
0x0002
(2)
0
W
System Command
N
Refer to system
command (P.19)
0x000C
(12)
0
R/W
Device Access Lock
Y
Refer to device access
lock (P.19)
0x0010
(16)
0
R
Vendor Name
N
SMC Corporation
0x0011
(17)
0
R
Vendor Text
N
www.smcworld.com
0x0012
(18)
0
R
Product Name
N
Example: D-MP025A
0x0013
(19)
0
R
Product ID
N
Example: D-MP025A
0x0014
(20)
0
R
Product Text
N
Actuator Position
Sensor
0x0015
(21)
0
R
Serial Number
N
8 octets fixed character
string
0x0016
(22)
0
R
Hardware Version
N
0x0017
(23)
0
R
Firmware Version
N
0x0018
(24)
0
R/W
Application Specific Tag
Y
16 octets fixed character
string
0x0024
(36)
0
R
Device Status
N
Refer to device status
parameter (P.19)
0x0028
(40)
0
R
Process Data Input
N
1: "R" means Read and "W" means Write.
2: Y: Included in DS (data storage), N: Not included in data storage.
