•System command (Index 2)
In the ISDU index 0x002 SystemCommand (system command), the command shown in the table below will
be issued.
The button of each system command is displayed on the IO-Link setting tool.
Click the button to send the system command to the product.
Command
(decimal number)
Command name
Evaluation method
0x41(65)
SP1 single value teach
Determined set point 1
0x42(66)
SP2 single value teach
Determined set point 2
0x80(128)
Device Reset
Restart the device
0x82(130)
Restore Factory Settings
Values are set to the factory settings
0xA8(168)
Teach measuring range start
Set the start position for measuring range
0xA9(169)
Teach measuring range end
Set the end position for measuring range
0xAA(170)
Reset measuring range
Measurement range reset
0xB0(176)
Warning reset
Reset the alarms
•Device access lock (Index 12)
Value
Evaluation method
0x02(2)
Lock the data storage
0x04(4)
Lock the local user interface
Data storage lock:
Sensor data storage function is disabled by locking the Data storage in the sensor.
In this case, access is rejected for data storage backup and restore.
Local user interface lock:
Position sensor operation by the teach pad is prohibited. If the teach pad is touched while locking, the green LED flashes
4 times. (SIO mode)
•Device status parameter (Index 36)
Readable device status is as follows.
Value
Definition of status
Evaluation method
0
Operated normally
-
1
The equipment should be inspected
Not available
2
Out of spec.
Temperature exceeded the upper limit, power supply voltage
decrease, Switch output short circuit detected
3
Check the functionality
Not available
4
Product break-down
Failed sensor
•Event
Event code
Event
Event class
0x4210(16912)
Exceeding the upper limit of the temperature
Warning
0x5000(20480)
Position sensor failure
Problems
0x5111(20753)
Decline in the power supply voltage
Warning
0x8CA8(36008)
Detectable magnetic field is decreased
Warning
