SMC Networks EtherNet/IP JXC91 Series User Manual

300
∗ Mountable on DIN rail
(35 mm)
84.2
64.235
(11.5)67
1.2
32.5
35
Ø 4.5
For body mounting (Screw mounting)
DIN rail mounting adapter
152.5
170
187.3 (When locking DIN rail)
193.2 (When removing DIN rail)
161
4.5
For bod
y
mountin
g
(
Screw mountin
g)
17.5(77)
7.5
(25)
(35)
L
5.5
5.2512.5
(Pitch)
1.25
Dimensions
Option: Conversion Cable Wiring Example
P5742-69 (Cable length: 0.3 m)
Power Supply Plug: PWR
PWR Power Supply Plug
Terminal name Function Details
0V Common supply (–)
M 24V terminal/C 24V terminal/EMG terminal/
BK RLS terminal are common (–).
M 24V Motor power supply (+) Motor power supply (+) of the controller
C 24V
Control power supply (+) Control power supply (+) of the controller
EMG Stop (+) Connection terminal of the external stop circuit
LK RLS Lock release (+) Connection terminal of the lock release switch
6
3
5
2
4
1
40V
2 M 24V
1 C 24V
5 N.C.
3 EMG 6 LK RLS
DIN rail
AXT100-DR-첸
∗ For 첸, enter a number from the “No.” line in the table below. Refer to the
dimensions above for the mounting dimensions.
L Dimension [mm]
No. 1 2 3 4 5 6 7 8 9 1011121314151617181920
L
23 35.5 48 60.5 73 85.5 98 110.5 123 135.5 148 160.5 173 185.5 198 210.5 223 235.5 248 260.5
No. 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
L
273 285.5 298 310.5 323 335.5 348 360.5 373 385.5 398 410.5 423 435.5 448 460.5 473 485.5 498 510.5
DIN rail mounting adapter
LEC-3-D0 (with 2 mounting screws)
This should be used when the DIN rail mounting adapter is mounted onto the screw mounting type controller afterwards.
4
Step Motor Controller
(EtherNet/IP™ Direct Input Type)
Series JXC91
