SMC Networks HRR012-A*-20 Series Operation Manual

HRX-OM-W004
Chapter 2 Contact input/output communication
HRR Series 2.4 Setting and checking
2-11
Contact output signal 3 Select maintenance
19. Press the [▼] key. Displays screen for setting the selected maintenance of Contact
output signal 3. The alarm is valid when the “selected maintenance status signal output”
is active.
Select the maintenance alarm No. to be allocated to Contact output signal 3.
●Setting range: MT.01 to MT.05 (Initial value: MT.01)
Contact output signal 3 Selected maintenance alarm No.
DOUT3 ⇒ MANT ⇒ CODE(Alternately displayed)
