SMC Networks HRR012-A*-20 Series Operation Manual

HRX-OM-W004
Chapter 1 Read before using
HRR Series 1.2 Communication port
1-3
1.2 Communication port
The communication port at the back of the product is used for communication.
Fig 1.2-1 shows the location of the communication port.
Fig 1.2-1 Communication port
Dsub 15 pin female (socket) type
Dsub 9 pin female (socket) type
Connector for contact in
p
ut / out
p
ut si
g
nal
Serial communication connector
8
1
15
9
5
1
9
6
