3. Product Specifications
3.1 Basic specifications
The basic specifications of this controller are as follows:
Item
Specifications
Compatible motor
Step Motor (Servo / 24 VDC)
Power supply
*1)
Power voltage: 24 VDC +/-10%
Max. current consumption: 3A (Peak 5A)
*2)
(for both of motor drive power control power,
stop, lock brake release)
Parallel input
11 inputs (photo-coupler isolation)
Parallel output
13 outputs (photo-coupler isolation)
Compatible encoder
Battery-less absolute encoder (resolution: 4096 pulses/rotation)
Incremental A/B phase (800 pulse / rotaion)
Serial communication
RS485
Memory
EEPROM
LED indicator
2 of LED’s (green and red)
Lock control
Forced-lock release terminal (Applicable to non -magnetizing lock.)
Cable length
I/O cable: 5m or less
Actuator cable: 20m or less
Cooling system
Natural air cooling
Operating temperature range
0 to 55
o
C
*3)
(No freezing)
Operating humidity range
90%RH or less (No condensation)
Storage temperature range
-10 to 60
o
C (No freezing)
Storage humidity range
90%RH or less (No condensation)
Insulation resistance
Between external terminals and case
50MΩ (500VDC)
Mass
150g (screw mount type)
170g (DIN rail mount type)
*1) The controller power supply do not use the power supply of "inrush current restraining type".
*2) The power consumption changes depending on the electric actuator model.
Please refer to the specifications of the electric actuator for more details.
*3) For the LEY40 and LEYG40 series compatible with battery-less absolute encoder, if the vertical
transfer load is greater than the weight listed below, the controller must be used at an ambient
temperature of 40
o
C or less.
LEY40#EA: 9 kg, LEY40#EB: 19 kg, LEY40#EC: 38 kg
LEYG40#EA: 7 kg, LEYG40#EB: 17 kg, LEYG40#EC: 36 kg
