8
28 20
2 x 3.418
3
13
(30.9)
38.5 1.4
10.2
46.9 (Max. 53.9)
DC(+)
OUT2
DC(–)
OUT1
18
48
58
68
76
A
Q
8
28 20
2 x 3.418
3
13
(30.9)
38.5 1.4
10.2
46.9 (Max. 53.9)
DC(+)
OUT2
DC(–)
OUT1
18
48
58
68
76
Q
2 x Female thread
Port size: 1, 2
2 x
P
2 x P
2 x One-touch fitting
Applicable tubing O.D.:
ø4, ø6, ø8
Width across flats B
A
Dimensions
PF2M7mS-m1/2 (-L)
PF2M7mS-C4/C6/C8 (-L)
[mm]
Model
A P Q
PF2M710S-C4 (-L)
87.1 ø2.8 depth 8.4 ø2.5 depth 6
PF2M710/725/750S
-C6 (-L)
87.9 ø2.8 depth 8.4 ø2.5 depth 6
PF2M711S-C8 (-L)
96 ø2.8 depth 6.2 ø2.5 depth 5
[mm]
Model
A B P Q
PF2M710/725/750S
-01(-L)
94 14 ø2.8 depth 8.4 ø2.5 depth 6
PF2M710/725/750S
-N1(-L)
96 14 ø2.8 depth 8.4 ø2.5 depth 6
PF2M710/725/750S
-F1(-L)
98 14 ø2.8 depth 8.4 ø2.5 depth 6
PF2M711S-02 (-L)
98 17 ø2.8 depth 6.2 ø2.5 depth 5
PF2M711S-N2 (-L)
98 17 ø2.8 depth 6.2 ø2.5 depth 5
PF2M711S-F2 (-L)
106 21 ø2.8 depth 6.2 ø2.5 depth 5
20
2-Color Display
Digital Flow Switch
PF2M7(-L) Series
