PF2M7-L Series
Compatible Products
Made to Order
Please contact SMC for detailed specifications, delivery times, and prices.
Compatible with Argon (Ar) and Carbon Dioxide (CO2) Mixed Gas
X731
Symbol
The argon–carbon dioxide gas ratio (Ar : CO2) can be selected using the push-buttons from among the following: 92 : 8, 90 : 10, 80 : 20, 70 : 30,
60 : 40, 40 : 60, and 30 : 70. The dimensions are the same as those of the standard model.
PF2M 7
For “How to Order,”
refer to page 10.
7
Integrated display
Model
Gas ratio
Rated flow range Display/Set point range
Max. analog output
Ar CO
2 Voltage (Vmax) Current (Imax)
PF2M701
92% 8%
0.01 to 1 L/min −0.05 to 1.05 L/min 5 V 20 mA
90% 10%
80% 20%
70% 30%
60% 40%
40% 60%
0.01 to 0.6 L/min −0.03 to 0.63 L/min 5 V 20 mA
30% 70%
PF2M702
92% 8%
0.02 to 2 L/min −0.1 to 2.1 L/min 5 V 20 mA
90% 10%
80% 20%
70% 30%
60% 40%
40% 60%
0.02 to 1.2 L/min −0.06 to 1.26 L/min 5 V 20 mA
30% 70%
PF2M705
92% 8%
0.05 to 5 L/min −0.25 to 5.25 L/min 5 V 20 mA
90% 10%
80% 20%
70% 30%
60% 40%
40% 60%
0.05 to 3 L/min −0.15 to 3.15 L/min 5 V 20 mA
30% 70%
PF2M710
92% 8%
0.1 to 10 L/min −0.5 to 10.5 L/min 5 V 20 mA
90% 10%
80% 20%
70% 30%
60% 40%
40% 60%
0.1 to 6 L/min −0.3 to 6.3 L/min 5 V 20 mA
30% 70%
PF2M725
92% 8%
0.3 to 25 L/min −1.3 to 26.3 L/min 5 V 20 mA
90% 10%
80% 20%
70% 30%
60% 40%
40% 60%
0.3 to 15 L/min −0.8 to 15.8 L/min 5 V 20 mA
30% 70%
PF2M750
92% 8%
0.5 to 50 L/min −2.5 to 52.5 L/min 5 V 20 mA
90% 10%
80% 20%
70% 30%
60% 40%
40% 60%
0.5 to 30 L/min −1.5 to 31.5 L/min 5 V 20 mA
30% 70%
PF2M711
92% 8%
1 to 100 L/min −5 to 105 L/min 5 V 20 mA
90% 10%
80% 20%
70% 30%
60% 40%
40% 60%
1 to 60 L/min −3 to 63 L/min 5 V 20 mA
30% 70%
* When changing the max. analog output, use the analog free span function on page 25.
X731
L
Output specification
Symbol OUT1 OUT2
L
IO-Link/NPN/PNP —
L2
IO-Link/NPN/PNP NPN/PNP/External input
L3
IO-Link/NPN/PNP Analog 1 to 5 V ⇔ Analog 0 to 10 V
L4
IO-Link/NPN/PNP Analog 4 to 20 mA
* Only applicable to the IO-Link output specification
23
