SMC Networks PF2M7 Series Manual

18 x n pcs. + 34.4
18
4838.5
7.5
(25) (35)
L
5.5
5.2512.5
(Pitch)
1.25
(5)
Brown
White
Black
Blue
(6.5)
+21−
(20
)
(30)
Terminal semi-stripped
(2020)
Dimensions
PF2M701/702/705/710/725/750/711(-L)
* For m, enter a number from the No. line in the table below.
DIN rail
AXT100-DR-m
DIN rail mounting bracket
ZS-33-Rm
L Dimensions [mm]
No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
L
23 35.5 48 60.5 73 85.5 98 110.5 123 135.5 148 160.5 173 185.5 198 210.5 223 235.5 248 260.5
Lead wire with connector
ZS-33-D
Cable Specifications
* For wiring, refer to the Operation Manual from the SMC website
Documents/Download --> Instruction Manuals.
Conductor
Nominal cross section AWG 26
Outside diameter Approx. 0.50 mm
Insulator
Outside diameter Approx. 1.00 mm
Color Brown, White, Black, Blue
Sheath Material Oil-resistant PVC
Finished outside diameter ø3.5
22
2-Color Display
Digital Flow Switch
PF2M7(-L) Series
