Configuring the Gateway
86
SMCD3GNV Wireless Cable Modem Gateway User Manual
Figure 47. Add Service Menu
Table 19. Add Service Menu
Option Description
Service Name Name for identifying the service. The name is for reference purposes only.
Service Type The protocol you want to use with the service. Choices are:
• TCP
• UDP
• TCP/UDP (default)
Service IP Address IP address of the LAN computer or server that is running the service.
Start Public Port Starting number of the port on which the service is provided.
End Public Port Ending number of the port on which the service is provided. This field is unavailable if the
Gateway is configured for a single public IP port.
Private Port(s) Numbers of the ports whose traffic the Gateway forwards to the LAN. If there is a range of
ports, enter the starting private port here and check Enable Port Range. The Gateway
automatically calculates the end private port. The LAN computer server listens for traffic/data
on this port (or these ports).
Enable Port Range Check this box to enable the private port range specified in Private Port(s).
SAVE button Click this button to save your settings.
CANCEL button Click this button to discard your settings on the Add Blocked Device menu.
