Delay time selection
Select from • 1.5 ms or less
• 20 ms • 100 ms • 500 ms
• 1000 ms • 2000 ms • 5000 ms.
Display colour selection
Select from • ON
Green
/OFF
Red
• ON
Red
/OFF
Green
• Normally
Red
/Normally
Green
.
Mode selection
Output mode selection
Select from • Hysteresis mode
• Window comparator mode
• Error output • Output OFF.
Selection of normal
or reversed
Select from • Normal output
• Reversed output.
Set value (Threshold
value) setting
• Adjust the numerical value.
Hysteresis value setting
• Adjust the numerical value.
3 Setting Modes
Setting mode can be selected according to the purpose.
3 Step Setting
Mode
Completion of Setting Completion of Setting Completion of Setting
Simple Setting
Mode
Function
Selection Mode
Press the
button once.
Press the button
between 1 and 3 seconds.
Press the button
between 3 and 5 seconds.
Settings
• Threshold value setting
or
•
Hysteresis value setting
Simple
Higher
function
• Output mode selection
•
Selection of normal or reversed
• Threshold value setting
• Hysteresis value setting
• Delay time selection
• Display colour selection
High-Precision Digital Pressure Switch
3-Screen Display
• Threshold value setting
•
Hysteresis value setting
• Delay time selection
2
