3-Screen Display
High-Precision Digital Pressure Switch
How to Order
ISE20
ZSE20
M5
M5
N
N
M
M
For positive pressure
For vacuum/compound pressure
Rated pressure range
ISE20
−0.1 to 1 MPa
Rated pressure range
ZSE20
0 to −101 kPa
ZSE20F
−100 to 100 kPa
Output specification
Symbol Description
N
NPN open collector 1 output
P
PNP open collector 1 output
Unit specification
Symbol Description
—
With unit selection function
M
SI unit only
Note)
P
With unit selection function (Initial value psi)
Note) Fixed unit: kPa, MPa
Piping specification
Symbol Description
M5
M5 Female
thread
01
R 1/8
N01
NPT 1/8
Option 3
Symbol Operation Manual Calibration certifi cate
—
앪
—
Y
——
K
앪앪
T
—
앪
Option 1
Symbol Description
—
Without lead wire
L
Lead wire with
connector
(Lead wire length 2 m)
ZS-46-3L
Option 2
Symbol Description
—
None
A1
Bracket A
(Vertical
mounting)
ZS-46-A1
A2
Bracket B
(Horizontal
mounting)
ZS-46-A2
B
Panel mount
adapter
ZS-46-B
D
Panel mount
adapter + Front
protection cover
ZS-46-D
Pin
Concave
Connector
Series ZSE20(F)/ISE20
5
