Bracket A Bracket B
Panel mount
Mounting
Bracket confi guration allows mounting in four orientations.
Mountable side by side
without clearance
One opening!
· Reduced panel fi tting labour
· Space saving
Mounting exampleMounting example
Introduction of Series
−101 kPa
0
0.0 to −101.0 kPa
Series Output Piping Withstand pressure
Smallest settable
increment
Rated pressure range Set pressure range
−0.105 to
1.050 MPa
1.5 MPa 0.001 MPa
−105.0 to
105.0 kPa
500 kPa 0.1 kPa
NPN or PNP
open collector
1 output
M5 Female
thread,
R 1/8,
NPT 1/8
10.0 to
−105.0 kPa
500 kPa 0.1 kPa
−100 kPa
100 kPa
0
−100.0 to 100.0 kPa
1 MPa
0
−0.1 MPa
(−100 kPa)
−0.100 to 1.000 MPa
ISE20
(Positive
pressure)
ZSE20
(Vacuum
pressure)
ZSE20F
(Compound
pressure)
High-Precision Digital Pressure Switch
3-Screen Display
