Specifi cations
Model
ZSE20 (Vacuum pressure)
ZSE20F (Compound pressure)
ISE20 (Positive pressure)
Applicable fluid Air, Non-corrosive gas, Non-flammable gas
Pressure
Rated pressure range 0.0 to −101.0 kPa −100.0 to 100.0 kPa −0.100 to 1.000 MPa
Set pressure range 10.0 to −105.0 kPa −105.0 to 105.0 kPa −0.105 to 1.050 MPa
Smallest settable increment 0.1 kPa 0.001 MPa
Withstand pressure 500 kPa 1.5 MPa
Electrical
Power supply voltage 12 to 24 V DC ±10 %, Ripple (p-p) 10 % or less
Current consumption 25 mA or less
Protection Polarity protection
Accuracy
Display accuracy
±2 % F.S. ±1 digit (Ambient temperature of 25 ±3 °C)
Repeatability
±0.2 % F.S. ±1 digit
Temperature characteristics
±2 % F.S. (25 °C reference)
Switch output
Output type NPN or PNP open collector 1 output
Output mode Hysteresis mode, Window comparator mode, Error output, Output OFF
Switch operation Normal output, Reversed output
Maximum load current 80 mA
Maximum applied voltage (NPN only)
28 V
Internal voltage drop (Residual voltage)
1 V or less (with load current of 80 mA)
Delay time
Note 1)
1.5 ms or less (with anti-chattering function: 20, 100, 500, 1000, 2000, 5000 ms)
Hysteresis
Hysteresis mode
Variable from 0
Note 2)
Window comparator mode
Short circuit protection Yes
Display
Unit
Note 3)
MPa, kPa, kgf/cm
2
, bar, psi, InHg, mmHg MPa, kPa, kgf/cm
2
, bar, psi
Display type LCD
Number of screens 3-screen display (Main screen, Sub screen x 2)
Display colour
1) Main screen: Red/Green
2) Sub screen: Orange
Number of display digits
1) Main screen: 4-digit (7-segment)
2) Sub screen: 4-digit (Upper 1-digit 11-segment, 7-segment for other)
Indicator light Lights up when switch output is turned ON. OUT1: Orange
Digital filter
Note 4)
0, 10, 50, 100, 500, 1000, 5000 ms
Environment
Enclosure IP40
Withstand voltage 1000 V AC for 1 minute between terminals and housing
Insulation resistance 50 MΩ or more (500 V DC measured via megohmmeter) between terminals and housing
Operating temperature range Operating: −5 to 50 °C, Stored: −10 to 60 °C (No freezing or condensation)
Operating humidity range Operating/Stored: 35 to 85 % RH (No condensation)
Standards CE, RoHS
Length of lead wire with connector 2 m
Note 1) Value without digital filter (at 0 ms)
Note 2)
If the applied pressure fluctuates around the set value, the hysteresis must be set to a value more than the amount of fluctuation or chattering will occur.
Note 3) This setting is only available for models with the unit selection function. Only MPa or kPa is available for models without this function.
Note 4) The response time indicates when the set value is 90 % in relation to the step input.
Piping Specifications and Weights
Model M5 01 N01
Port size M5 x 0.8 R 1/8 NPT 1/8
Materials of
parts in contact
with fluid
Sensor pressure receiving area
Silicon
Piping port (Common)
PBT, CB156, Heat resistant PPS, O-ring: HNBR
Piping port —
C3604 (Electroless nickel plating), Stainless steel 304, NBR
Weight
Body 22 g 30 g
Lead wire with connector
+35 g
When optional parts are required separately, use the following part numbers to place an order.
Description Part number Note
Bracket A
ZS-46-A1
Tapping screw: Nominal size 3 x 8 L (2 pcs.)
Bracket B
ZS-46-A2
Tapping screw: Nominal size 3 x 8 L (2 pcs.)
Panel mount adapter
ZS-46-B
—
Panel mount adapter + Front protection cover
ZS-46-D
—
Lead wire with connector
ZS-46-3L
3 cores, 2 m
Front protection cover
ZS-27-01
—
R 1/8 Piping adapter
ZS-39-N1
—
NPT 1/8 Piping adapter
ZS-39-N2
—
Cable Specifications
Conductor area 0.15 mm
2
(AWG26)
Insulator
Outside diameter
1.0 mm
Colour
Brown, Blue, Black (3 cores)
Sheath
Finished outside diameter
Ø 3.4
Options/Part Numbers
6
3-Screen Display
High-Precision Digital Pressure Switch
Series ZSE20(F)/ISE20
