3020 ±0.1
20 ±0.1
25 5
30
Lead wire with connector
1.5M5 x 0.8
15.2
A
N01
M5
01
Dimensions
Z/ISE20(F)
Piping specifi cation
M5 Female thread
R 1/8
NPT 1/8
Piping specifi cation Port size
A
01
R 1/8 Width across fl ats 10
N01
NPT 1/8 Width across fl ats 12
8
3-Screen Display
High-Precision Digital Pressure Switch
Series ZSE20(F)/ISE20
