SME AC-M1 User Manual

K2 connector pin-out for AC-M1 : PUMP application
Pin Name I/O Specification Function
9 GND ENC Negative logic supply
10
analogue
input
Pull-up Reserve
11 T. MOTOR 1
analogue
input
Pull-up
Analogue input for pump motor
thermal sensor
12
digital
input
4mA pull-up,
VL<=1V,
VH>=3,5V
Reserve
13 LIFT PRESSURE
analogue
input
0/12V pull-down
Lift pressure sensor
14 AUX 1
digital
input
4mA pull-up,
VL<=1V,
VH>=3,5V
Aux1 request
15 AUX2
digital
input
4mA pull-up,
VL<=1V,
VH>=3,5V
Aux2 request
16
digital
input
4mA pull-up,
VL<=1V,
VH>=3,5V
Reserve
17 LIMITATION 1
digital
input
4mA pull-up,
VL<=1V,
VH>=3,5V
Limitation speed 1
18
digital
input
4mA pull-up,
VL<=1V,
VH>=3,5V
Reserve
19
analogue
input
0/12V pull-down Reserve
20
analogue
input
0/12V pull-down Reserve
21
analogue
input
0/12V pull-down Reserve
22 LIFT LEVER
analogue
input
0/12V pull-down Lift speed request
23 LIMITATION 2
digital
input
pull-down,
max input: 24V 4mA,
VL<=1V,
VH>=3,5V
Limitation speed 2
PRELIMINARY VERSION 16
