SME AC-M1 User Manual

Maximum impulsive inverter current (2'):
AC-M1 36/48V 375A
AC-M1 36/48V 500A
375Aac
500Aac
Motor switching frequency:
9KHz
Efficiency:
95%
Protection level:
IP65
Mechanical size:
210x145x91 mm
Weight:
3.8 kg
Vibration:
5g 10/500Hz 3 axis
Working temperature range:
-30/+40°C
Storage temperature range:
-40/+50°C
Maximum case temperature:
100°C
Regulation compliance:
EN1175 for safety
EN12895 for for Electromagnetic comp ability
UL Recognized Component; meets UL583
dielectric test
Technical specifications for the 72V – 80V AC-M1
Battery voltage: 72V – 80V
PRELIMINARY VERSION 27
