Maximum impulsive inverter current (2'):

AC-M1 72/80V 350A

AC-M1 72/80V 450A

350Aac

450Aac

Motor switching frequency:

9KHz

Efficiency:

95%

Protection level:

IP65

Mechanical size:

210x145x91 mm

Weight:

3.8 kg

Vibration:

5g 10/500Hz 3 axis

Working temperature range:

-30/+40°C

Storage temperature range:

-40/+50°C

Maximum case temperature:

100°C

Regulation compliance:

EN1175 for safety

EN12895 for for Electromagnetic comp ability

UL Recognized Component; meets UL583

dielectric test

PRELIMINARY VERSION 28
