Installation
85
EN
Assembling the upstand
The upstand must always be positioned and
secured correctly on the appliance.
1. Position the upstand on the hob, taking
care to line up holes A with holes B.
Secure the upstand to the top by tightening
screws C.
Installing the grille strip
If the appliance is installed as an island, the
strip provided should be installed instead of
the upstand.
Use the 3 screws, provided, to secure the
strip to the hob. Fasten it using the middle
screw (1) first and then the side screws (2).
The upstand should only be
installed if the appliance is wall
mounted.
The upstand provided is an
integral part of the product. It must
be fastened to the appliance prior
to installation.
The strip should only be installed if
the appliance is installed as an
island.
