Instructions for the installer
103
11.7 Wall mounting instructions (some markets only)
1 Fasten a hook bolt (not supplied) into the
wall at a height (h) of 800 mm from the
floor.
The installer must provide the hook bolt when installing the appliance.
2 Attach the snap hook to the chain.
3 Attach the end of the chain to the hook
bolt fastened in the wall.
4 Finally, connect the snap hook to the
appropriate hole on the back of the
appliance.
