Smeg A5-8 - Burner and Nozzle Characteristics Table

Instructions for the installer
105
12.2 Burner and nozzle characteristics table
For burner arrangement, see “Instructions for the user - 6.4 Cookware
diameters”.
Burner
Rated
heating
capacity
(kW)
Natural gas – G20 20 mbar
Nozzle diameter
1/100 mm
Reduced capacity
(W)
1
Auxiliary 1.05 72 (X) 400
2
Semi-rapid 1.8 97 (Z) 500
3
Rapid 3.0 115 (Y) 800
4
Ultra-rapid 3.9 135 (K) 1600
5
Fish burner 1.9 94 (X) 800
6
UR2 inner crown 1.0 70 (K) 400
6
UR2 outer crown 3.6 102 + 102 (K) 1600
Burner
Rated
heating
capacity
(kW)
LPG – G30/G31 28/37 mbar
Nozzle
diameter
1/100 mm
Reduced
capacity
(W)
Capacity
g/h G30
Capacity
g/h G31
1
Auxiliary 1.05 50 400 76 75
2
Semi-rapid 1.8 65 500 131 129
3
Rapid 3.0 85 800 218 215
4
Ultra-rapid 3.9 100 1600 284 279
5
Fish burner 1.9 68 800 138 136
6
UR2 inner crown 1.0 46 400 73 71
6
UR2 outer crown 3.6 68 + 68 1600 284 250
