CW/CWH–511MDA

9
FORMODELSWITHAWATERSOFTENER
AN ‘APPROVED’ DOUBLE CHECK VALVE OR SOME OTHER NO LESS  EFFECTIVE  DEVICE PROVIDING
BACKFLOWPREVENTIONPROTECTIONTOATLEASTFLUIDCATEGORYTWOSHALLBEFITTEDATTHE
POINTOFCONNECTIONBETWEENTHEWATERSUPPLYANDTHEFITTINGORAPPLIANCE.

FORMODELSWITHOUTAWATERSOFTENER
AN ‘APPROVED’ SINGLE CHECK VALVE OR SOME OTHER NO LESS EFFECTIVE DEVICE PROVIDING
BACKFLOWPREVENTIONPROTECTIONTOATLEASTFLUIDCATEGORYTWOSHALLBEFITTEDATTHE
POINTOFCONNECTIONBETWEENTHEWATERSUPPLYANDTHEFITTINGORAPPLIANCE.

Thedynamicwatersupplypressure mustbebetween1and6bar;ifitishigherapressurereducer
mustbeinstalled.
Itisessentialtofitamainstoptaponthewaterintakedeliverpipeline;thetapmustbeaccessible
afterinstallationoftheappliance,sodonotinstallitbehindthewarewasher.Thestatedcycle
durationappliestoappliancessuppliedwithhotwater>50°C<60°CIfthewarewasherissupplied
withcoldwater,thecycledurationmightincreasedependingontheintakewatertemperature.

Thewarewasherisfittedwithadrainpumpandcanoperatewithdrainconnectionsontheflooror
wall.
Refertotheconnectiondiagramforthemaximumpermittedheightofwalldrains–(seeTECHNICAL
DATA)


Caution:makesurethattheintakeanddrainhosesarenotbent,constrictedorcrushed
afterinstallation.


When installing the drain hose to a siphon with valve, the maximum height of the drain outlet is
reducedto600mm.














