Instructions for the installer
40
Complete wiring up to power supply with an appropriately rated five-core
plug (see data plate) or, in case of operation from a 220-240V∼ power
supply, with a three-core plug. Make sure that plug and wall socket are of
the same type and are in conformity with regulations in force. Make sure
that the appliance is properly earthed. Before powering, check that the
power line is properly earthed. Avoid using adapters or shunts.
The manufacturer cannot be held liable for damage to persons or
things caused by failure to comply with the above requirements or by
tampering with any part of the appliance.
2.2 Mounting the rear skirt
• Position the skirt above the top, taking care to align holes A with holes
B.
• Secure the skirt to the top by tightening screws C.
Warning: the rear skirt (or optional back panel) must be fitted to prevent
the rear wall from overheating.
2.3 Levelling
Level the appliance on the ground by means of its four adjustable feet. In
order to adjust them, loosen the lock nut and unscrew the foot. The
adjustment screws have a range of 10 mm.
